Large Size, High Efficiency, Great Productivity
- Compared with EP-A650 SLA 3d printing machine, the build volume is increased by 85% to 800mm*800mm*450mm.
- Based on the dynamic optimization of printing path algorithm andthe patented VarioBeam technology, the printing efficiency is doubled.
- With dual-laser, the printing speed is 30%~45% faster than single-laser.
-
Patented VarioBeam Technology,which has a high positioning accuracy, ensures processing efficiency and surface quality as well.
-
Liquid-level Control Technology, the adjustment accuracy is within ±0.01mm; automatic detection during printing, dynamic fine adjustment.
-
Automatic detection during printing, dynamic fine adjustment.
-
The design of machine hardware framework is optimized and more stable.
-
00-level marble platform to improve the motion accuracy and long-term stability.
-
Offering material, related applications technology support for prototype part shell, structure testing, jigs and fixtures, investment casting, prototype rollover, medical models and guidance boards
-
Eplus3D SLA 3d printing service offering variety material’s printing parameter packages and opening common parameter adjustment for users’ fine tune.
-
Open material selection, compatible with main 355 nm photosensitive resin in market
What Can EP-A800 Laser Resin 3D Printer Print?
Architecture Model
- Machine:EP-A800
- Process:Stereolithography (SLA)
- Material: SH9100
Size:Φ520x290x200mm
Application:Molding
EP-A800 Laser Resin 3D Printer Specifications
| Machine Model | EP-A800 |
| Build Volume (X*Y*Z) | 800mm*800mm*450mm （The height can be customized up to 550mm） |
| Build Accuracy* | ± 0.15 mm (L＜100 mm) ± 0.15% xL (L ≥100 mm) |
| Layer Thickness | 0.05mm~0.25mm |
| Scan speed | Typical speed: 6－12m/s |
| Max. weight of one-time produced part | 120Kg |
| Laser | DPSSL (Diode-pumped solid-state laser), 3W |
| Optical scanning system | Galvanometer Scanners system |
| Optical focusing system | F-theta lens |
| Spot size | Invariant spot: 0.08-0.2mm Variant spot: 0.08~0.8mm（VarioBeam Module required） |
| Motion platform | Marble platform（00 level） |
| Control software | Self-developed software EPResin |
| Data format | *.stl /*.slc/*.cli/*.epi |
| Equipment IPC | I3，2.1GHz Frequency, 4GB Memory; Windows® 7 or Windows® 10 |
| Dimensions (L*W*H) | Without package: 1650mm*1500mm*2250mm With package: 1850mm*1700mm*2500mm |
| Machine Weight | 1500KG（without resin） |
| Power Supply | 200-240VAC,50/60Hz, single phase |
| Operating Temperature | 20-26℃ |
| Operating Humidity | Less than 40% |
| Installation ground | Solid, level, no vibration |
